Udvidelses moduler

With the expansion modules from DOLD, you can simply multiply the output contacts of the basic modules in order to be able to deactivate any number of control circuits safely. These are compact switching devices with forcibly guided safety relays that are controlled by the respective function module (basic module) and monitored via a return circuit. A cost-effective contact multiplication is made possible through the division into multiple control circuits.
Extension module LG 5929
• According to
- Performance Level (PL) e and category 4 to EN ISO 13849-1: 2008
- SIL Claimed Level (SIL CL) 3 to IEC/EN 62061
- Safety Integrity Level (SIL) 3 to IEC/EN 61508
when connected to a suitable safety module
• Control from semiconductor safety outputs (light curtains,
e-stop, etc.) is also possible
• Redundant and forcibly guided contacts
• Output: max. 5 NO contacts or 4 NO contacts / 1 NC contact
• 1-channel or 2-channel connection
• LED indication for operation
• Removeable terminal strips
• Wire connection: also 2 x 1.5 mm2 stranded ferruled, or
2 x 2.5 mm2 solid DIN 46 228-1/-2/-3/-4
• As option with pluggable terminal blocks for easy exchange
of devices
- with screw terminals
- or with cage clamp terminals
• Width 22.5 mm		Download datablad
Extension module BG 5929
• According to
- Performance Level (PL) e and category 4 to EN ISO 13849-1: 2008
- SIL Claimed Level (SIL CL) 3 to IEC/EN 62061
- Safety Integrity Level (SIL) 3 to IEC/EN 61508
when connected to a suitable safety module
• Redundant and forcibly guided contacts
• Output: max. 5 NO contacts or 4 NO contacts / 1 NC contact
• 1- or 2-channel connection
• LED indication for operation
• Removeable terminal strips
• Wire connection: also 2 x 1.5 mm2 stranded ferruled (isolated),
DIN 46 228-1/-2/-3/-4 or
2 x 2.5 mm2 stranded ferruled DIN 46 228-1/-2/-3
• Width 22.5 mm		Download datablad
Extension module BN 3081
• According to
- Performance Level (PL) e and category 4 to EN ISO 13849-1: 2008
- SIL Claimed Level (SIL CL) 3 to IEC/EN 62061
- Safety Integrity Level (SIL) 3 to IEC/EN 61508
when connected to a suitable safety module
• Redundant and forcibly guided contacts
• Output: 7 NO contacts, 1 NC contact for feed back circuit
• 1- or 2-channel connection
• LED displays for channels 1.2
• Removable terminal strips
• Width 100 mm		Download datablad
Extension module UG 6929
• According to
- Performance Level (PL) e and category 4 to EN ISO 13849-1: 2008
- SIL Claimed Level (SIL CL) 3 to IEC/EN 62061
- Safety Integrity Level (SIL) 3 to IEC/EN 61508 and IEC/EN 61511
when connected to a suitable safety module
• According to EN 50156-1 for furnaces
• Control with safety semiconductor outputs (light curtain, e-stop) possible
• Redundant and forcibly guided contacts
• Output: max.7 NO or 6 NO contacts / 1 NC contact, 1 NC contact for
feedback circuit
• 1- or 2-channel
• Indication
• As option with pluggable terminal blocks for easy exchange of devices
- with screw terminals
- or with cage clamp terminals
• Width: 22.5 mm		Download datablad
